Intel Core Ultra 5 250K Plus LGA1851 Desktop Processor, 18 Cores, Up to 5.3GHz, 30MB Cache, DDR5-7200, Intel Graphics, 30 TOPS AI, PCIe 5.0, Thunderbolt 4 and 159W Turbo Power | BOXED

Expert Features 18-Core Arrow Lake Power : Combines 6 Performance-cores and 12 Efficient-cores for 18 total cores and 18 threads, adding four E-cores over the previous Core Ultra 5 245K for stronger multitasking, gaming, streaming, and creation workloads. Up to 5.3GHz Turbo Performance : Performance-cores reach up to 5.3GHz, while Efficient-cores boost up to 4.6GHz, giving demanding games and responsive desktop applications serious single-core speed without sacrificing background-task muscle. 30MB Smart Cache and 30MB L2 : A large 30MB Intel Smart Cache works alongside 30MB of total L2 cache to keep frequently used game data, application instructions, and processor workloads close to the cores. Unlocked K-Series Tuning : Designed for enthusiast desktop systems with support for Intel Extreme Memory Profile, Intel Application Optimization, and the new Intel Binary Optimization Tool for compatible games and supported configurations. Overclocking results depend on the motherboard, cooling, BIOS, and silicon quality. Built-In AI Acceleration : Delivers up to 30 overall peak INT8 TOPS through CPU, integrated graphics, and the Intel AI Boost NPU, enabling compatible AI workloads without dumping every smart background feature onto the CPU cores. Dedicated Intel AI Boost NPU : The integrated NPU supplies up to 13 INT8 TOPS with sparsity and Windows Studio Effects support for compatible AI-enhanced communication, productivity, and creative applications. DDR5-7200 Memory Support : Supports up to 256GB of dual-channel DDR5 memory at up to 7200MT/s, including ECC memory support when paired with compatible motherboard hardware and memory modules. LGA1851 Desktop Platform : Uses the FCLGA1851 socket and maintains compatibility with Intel 800-series chipset motherboards, although a motherboard BIOS update may be required for the Plus-series processor. PCIe 5.0 and 4.0 Expansion : Provides up to 24 processor PCIe lanes with flexible configurations including x16 graphics plus dual x4 connections for high-speed GPUs and NVMe storage. Integrated Intel Graphics : Includes four Xe cores running up to 1.9GHz, supporting up to four displays, 8K output, DirectX 12, Intel Quick Sync Video, and hardware H.264, HEVC, and AV1 encoding and decoding. Creator-Friendly Media Engine : Hardware AV1, HEVC, and H.264 encode/decode acceleration helps compatible video-editing, recording, streaming, and media-conversion applications work more efficiently. Integrated Thunderbolt 4 Support : Intel officially lists integrated Thunderbolt 4 support; Thunderbolt 5 requires a compatible discrete motherboard implementation and should not be presented as an integrated CPU feature. 125W Enthusiast Power Class : Operates with a 125W processor base power and up to 159W maximum turbo power, making a high-quality LGA1851 motherboard and capable CPU cooler essential—not optional decoration. Intel vPro Enterprise Eligible : Supports Intel AMT, Threat Detection Technology, Remote Platform Erase, One-Click Recovery, SIPP, advanced encryption, and virtualization technologies when paired with an eligible business platform. No Hyper-Threading Architecture : Runs one thread per Performance-core and Efficient-core for 18 total threads, using Intel Thread Director to help compatible operating systems distribute work across the hybrid core layout. Expert Specs Specification Value Brand Intel Product Family Intel Core Ultra 5 Product Collection Intel Core Ultra Processors Series 2 Exact Processor Intel Core Ultra 5 Processor 250K Plus Processor Number 250K PLUS Code Name Products Formerly Arrow Lake Vertical Segment Desktop Architecture Revision Arrow Lake Refresh / Core Ultra 200S Plus Marketing Status Launched Launch Quarter Q1 2026 Retail Availability Date March 26, 2026 Total Cores 18 Performance-Cores 6 Efficient-Cores 12 Low-Power Efficient-Cores 0 Total Threads 18 Hyper-Threading No Maximum Turbo Frequency Up to 5.3GHz Performance-Core Maximum Turbo Up to 5.3GHz Efficient-Core Maximum Turbo Up to 4.6GHz Performance-Core Base Frequency 4.2GHz Efficient-Core Base Frequency 3.3GHz Intel Smart Cache 30MB Total L2 Cache 30MB Processor Base Power 125W Maximum Turbo Power 159W Maximum Operating Temperature 105°C CPU Lithography TSMC N3B Overall Peak AI Performance Up to 30 INT8 TOPS CPU AI Acceleration Intel Deep Learning Boost CPU AI Frameworks OpenVINO, WindowsML, DirectML, ONNX Runtime and WebNN NPU Intel AI Boost NPU Peak Performance Up to 13 INT8 TOPS NPU Sparsity Support Yes Windows Studio Effects Supported NPU AI Frameworks OpenVINO, WindowsML, DirectML, ONNX Runtime and WebNN Maximum Memory Capacity 256GB Supported Memory Type DDR5 Maximum Official Memory Speed Up to DDR5-7200MT/s Maximum Memory Channels 2 ECC Memory Support Yes, With Compatible Platform Hardware Intel XMP Support Yes, Platform and Memory Dependent Integrated GPU Intel Graphics GPU Xe-Cores 4 Graphics Base Frequency 300MHz Graphics Maximum Dynamic Frequency 1.9GHz GPU Peak AI Performance Up to 8 INT8 TOPS GPU Display Outputs eDP 1.4b, DisplayPort 2.1 UHBR20 and HDMI 2.1 FRL Maximum HDMI Resolution 4096 × 2304 at 60Hz Through HDMI 2.1 TMDS Maximum HDMI FRL Resolution 7680 × 4320 at 60Hz Maximum DisplayPort Resolution 7680 × 4320 at 60Hz Maximum eDP Resolution 3840 × 2400 at 120Hz Maximum Supported Displays 4 DirectX Support DirectX 12 OpenGL Support OpenGL 4.5 OpenCL Support OpenCL 3 H.264 Hardware Encode/Decode Yes H.265 / HEVC Hardware Encode/Decode Yes AV1 Hardware Encode/Decode Yes Intel Quick Sync Video Yes GPU Intel Deep Learning Boost Yes GPU AI Frameworks OpenVINO, WindowsML, DirectML, ONNX Runtime and WebGPU GPU Device ID 0x7D67 CPU Socket FCLGA1851 / LGA1851 Package Size 45 × 37.5mm Thermal Solution Specification PCG 2020A Compatible Chipset Family Intel 800-Series, Subject to Motherboard and BIOS Support DMI Revision DMI 4.0 Maximum DMI Lanes 8 PCI Express Revision PCIe 5.0 and PCIe 4.0 Maximum CPU PCIe Lanes 24 PCIe Configurations Up to 1×16 2×4, 2×8 2×4 or 1×8 4×4 Integrated Thunderbolt Support Thunderbolt 4 Thunderbolt 5 Discrete Platform Support Only; Requires Compatible Motherboard Hardware Scalability 1S Only Intel Gaussian and Neural Accelerator Version 3.5 Intel Thread Director Yes Intel Speed Shift Technology Yes Intel Turbo Boost Technology Version 2.0 Intel 64 Yes Instruction Set 64-Bit Instruction-Set Extensions Intel SSE4.1, SSE4.2 and AVX2 Idle States Yes Enhanced Intel SpeedStep Yes Thermal Monitoring Technologies Yes Intel Volume Management Device Yes Intel vPro Eligibility Intel vPro Enterprise Intel Threat Detection Technology Yes Intel Active Management Technology Yes Intel Standard Manageability Yes Intel Remote Platform Erase Yes Intel One-Click Recovery Yes Intel Secure Key Yes Control-Flow Enforcement Technology Yes Total Memory Encryption Multi-Key Yes Intel AES New Instructions Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel OS Guard Yes Intel Boot Guard Yes Mode-Based Execute Control Yes Intel Stable IT Platform Program Yes Virtualization With Redirect Protection Yes Intel Virtualization Technology VT-x Yes Intel Virtualization for Directed I/O VT-d Yes VT-x With Extended Page Tables Yes Embedded Options Available No Use Conditions PC, Client, Tablet and Workstation Boxed Ordering Code BX80768250K
