SAFE-T-LOCK Programmable Code Key Pad (99 User Codes)

The SAFE-T-LOCK is a waterproof programmable keypad that is an excellent way to control access to a vehicle. A code is required to enable the vehicle to crank. It is compatible with electric, gasoline, propane, and diesel lifts.Great for forklifts, Cushman/Taylor Dunn carts, sweeper/scrubbers, Bobcat skid steers, telehandlers, scissor lifts, boom lifts JLG and Genie and golf carts like Textron or E-Z Go.Features: • Voltage Range – 12 to 120VDC. • Expanded User Capability – Can be programmed for up to 99 users. After installation, it requires entry of a two-digit user number and valid four-digit access code before the vehicle or equipment can be operated. All user codes can be reprogrammed and unused user numbers can be temporarily disabled for additional security. • Last User Identification – Can identify to the supervisor the user number of the last user of a vehicle. • Automatic Shut-Off – Detects vehicle activity. If the vehicle has been inactive beyond a specified period of time, the switch will deactivate securing the vehicle. This feature is optional and can be activated or deactivated as desired. • Maintenance Alert – After 250 hours of accumulated vehicle usage time an audible beep will indicate that vehicle maintenance is due. After maintenance is performed, the cycle can be reset as desired. This feature is optional and can be activated or deactivated by supervisor. • Accumulated Time – Can accumulate total vehicle usage time. This accumulated time can be accessed through the Supervisor Code. The supervisor’s access code can be changed using the factory programmed reset code. • Installation – only requires 4-5 wires to connect. • UL, CE, & RoHS compliant.Safe-T-Lock STL1000 Operation InstructionsSafe-T-Lock STL1000 Installation InstructionsSafe-T-Lock STL1000 Programming ProcedureSpecifications: Case: ABS plastic, 4 1/4″ H x 2 3/4″ W x 1.0″ D. Two (2) 3/16″ mounting holes, 3 15/16″ center to center, IP65 water resistance Keypad: Contacts internally sealed, moisture resistant Voltage: Input range 12-120VDC Current: Less than 30 mA with unit inactive; less than 90 mA with unit active. Output: Contact rating up to 10A maximum through 24v. Maximum 1A contact rating above 36v. For loads greater than 10A use external relay.
